Textile Sling Overhaul - Securing and Lifting of Loads

REVIEW REPORT

Forankra España, S.L.U. has a lifting slings revision service, in which a technician will come to your facilities (exclusive service for mainland Spain) and will make the report free of charge.

Please contact us to know the conditions.

Textile Sling Overhaul - Securing and Lifting of Loads

APPLICABLE LEGISLATION

UNE-EN 1492-1:2001+A1:2009
Textile slings. Safety. Part 1: Flat woven webbing slings made of chemical fibers for general use.

SCOPE OF APPLICATION

Flat woven web slings intended for general purpose lifting operations, which are used to lift objects, materials or goods that do not deviate from specified requirements, safety factors or working load limits.
Lifting operations not covered by this standard include the lifting of persons, potentially hazardous materials such as molten metals and acids, glass sheets, splittable materials, nuclear reactors and where special conditions apply.

USE AND STORAGE

Flat woven webbing slings in accordance with the standard are suitable for use and storage in the following temperature range:

  • polyester and polyamide -40ºC to 100ºC;
  • polypropylene -40ºC to 80ºC.

OUT OF RANGE OF APPLICATION

The standard does not apply to the types of webbing slings listed below:

  • slings such as sack slings, nets (composed of several cross webbing straps sewn together), 'adjustable' slings, etc.;
  • slings made of woven tapes of monofilament yarns;
  • slings designed for operation prior to sling handling and intended not to be reused.

CHECK LIST INSPECTION POINTS

The following points, among others, should be checked and verified during the inspection:

  • List of slings in use
  • Safety requirements.
  • Tape width and thickness.
  • Tape.
  • Sewing.
  • Eyelets.
  • Workload limits.
  • Color codes.
  • Label.
  • Metallic components.
  • Certificate.
  • Instructions for use.

WHO CAN PERFORM THE INSPECTION?

The person designated to perform the inspections must be adequately trained and qualified by knowledge and practical experience, and instructed to perform the required verifications/inspections.
All examinations and inspections should be carried out by :

  • Competent people trained in the applicable regulations.
  • Official Organizations.
  • Manufacturers of lifting slings.

STANDARDS FOR CONSULTATION

  • Machinery Directive and CE Conformity Marking
    Directive 2006/42/EC of the European Parliament and of the Council of ... - EUR-Lex (europa.eu)
  • UNE-EN ISO 12100-2:2004. Safety of machinery. Basic concepts, general principles for design. Part 2: Technical principles (ISO 12100-2:2003).
  • UNE-EN ISO 12100:2012. Safety of machinery. General principles for design. Risk assessment and risk reduction (ISO 12100:2010).
  • UNE-EN 1677-1:2001+A1:2009. Accessories for slings. Safety. Part 1: Forged steel accessories, Class 8.
  • UNE-EN 1677-3:2002+A1:2008. Accessories for slings. Safety. Part 3: Self-locking forged steel hooks. Class 8.
  • UNE-EN 1677-4:2001+A1:2009. Accessories for slings. Safety. Part 4: Links, Class 8
  • UNE-EN 1677-5:2002+A1:2009. Accessories for slings. Safety. Part 5: Forged steel lifting hooks with safety latch. Class 4.
  • UNE-EN 1677-6:2002+A1:2009. Accessories for slings. Safety. Part 6: Links. Class 4.
  • UNE-EN ISO 7500-1:2000. Metallic materials. Verification of machines for static uniaxial tests. Part 1: Tensile/compression testing machines. Verification and calibration of the force measurement system (ISO 7500-1:1999).
  • UNE-EN ISO/IEC 17021:2006. Conformity assessment. Requirements for bodies performing audit and certification of management systems (ISO/IEC 17021:2006).
  • UNE-EN ISO 5084:1997. Textiles. Determination of thickness of textiles and textile products (ISO 5084:1996).
  • UNE-ISO/TS 9002:2017. Quality management systems. Guidelines for the application of the ISO 9001:2015 Standard. www.aenor.com
